20Kv Three Phase Oil Immersed Distribution Transformer

Name: 20Kv Three Phase Oil Immersed Distribution Transformer
Brand: Huawan New Energy Co. Ltd.
Availability: InStock

Huawan 20KV three-phase oil-immersed distribution transformer is designed with a capacity range from 100kVA to 3000kVA, ensuring reliable performance for medium-voltage power distribution systems.

20kv Transformer Price

Specifications of Three Phase Oil Immersed Distribution 20kv Transformer

Parameter	Details/Specifications
Rated Power	200 kVA ~ 10,000 kVA
Input Voltage	20 kV
Output Voltage	0.4 kV / 0.69 kV / 1 kV
Rated Frequency	50 Hz / 60 Hz
Capacity	500 L ~ 8000 L
Cooling Method	ONAN (natural oil cooling)/ONAF (oil air cooling)
Impedance Voltage	4% ~ 6%
Load Loss	< 2 W / kVA
Short-Circuit Loss	≤ 2%
Ambient Temperature	-5 °C~40 °C (can adapt to extreme weather conditions, high temperature resistant version can reach 50 °C)
Weight	1000 kg ~ 15,000 kg
External Dimensions	Customized according to power model: 1.8m x 3.0m x 5.0m
Insulation Level	F-grade (155 °C)/H-grade (180 °C)
Seismic Resistance	Grade 8 seismic resistance, suitable for installation in complex geological areas
Noise Level	≤ 60 dB (low-noise design, suitable for residential areas or offices)
Energy Saving Performance	Efficient design, compliant with energy-saving standards, reduces power consumption and operating costs
Corrosion Resistance	Highly corrosion-resistant oil, ensuring long-term efficient and stable operation
Operational Reliability	High reliability design, preventing short circuits and overloads, reducing failure rates

As one of the leading distribution transformer manufacturers, Huawan provides innovative, high-performance transformers tailored to meet global energy demands with superior reliability and efficiency.

Features of Three Phase Oil Immersed Distribution 20kv Transformer
